Charvel Model 6







Charvel Model 6

Year: 1989
  Color: black
  Notes:
Bridge system: Jackson locking tremolo
Body: Poplar
Neck/Fingerboard: Rock maple bolt-on/quarter-sawn Rosewood
Machine heads: Jackson SG-38 06
Controls: Volume, Tone, Mid-boost, Trhee 2-way mini-toggles
Pickups: J200 Dual coil bi-level (two), J50BC Humbucking (bridge position)

General Specifications:

Tremolo: Kahler® Standard

Body Composition:
Poplar

Neck Fingerboard Composition:
RockMaple through Body Neck/Quarter-Sawn Rosewood

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Cobalt Blue, Black Cherry, Red, Pearl White,Black

Control Functions:
One Volume, One Tone, Jackson Pre-Amp with Mid Boost, Three 2-way mMini-Toggles


Pickup Specifications:
Model Number: J200 (two)
Description: Dual Coil, Bi-level
Humbucking designed for use with
active circuitry.
"clearer" distortion.
Sr.(in K Hz): 9.90
Z (@Sr in MOhms): 1.8
Inductance (in Henries):2.4
Q (@Sr): 12.6
Output Level (@ Sr): +44.1dB
Magnetic Structure: Alnico V
Resistance (in KOhms): 11.65

Pickup Specifications:
Model Number: J50BC (one)
Description: High Frequency Bridge
Position Humbucking. Designed for use
with active circuitry.
Sr.(in K Hz): 6.58
Z (@Sr in MOhms): 5.9
Inductance (in Henries):5.3
Q (@Sr): 2.64
Output Level (@ Sr): +56.4dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 8.58
